Site plan for a parking lot: permit requirements, cost, and turnaround

Commercial parking lots require a site plan showing space count, dimensions, ADA- compliant stalls, ingress/egress, and setbacks. MySitePlan creates these drawings for $179–$279, delivered in 24 hours.

Need a site plan for your parking lot permit?

A parking lot site plan must show the lot dimensions, parking space count and layout, ADA compliant stall locations and access aisles, ingress and egress points, landscaping buffers, andsetbacks from property lines. MySitePlan creates these drawings for $179 (Commercial Detailed) or $279 (Commercial “The Works” — includes topography, impervious surfacecalculation, and DWG file), delivered in 24 hours. Unlimited revisions included.
→ ADA stalls called out explicitly
→ Both plan tiers named with prices
→ DWG file option surfaced for engineers

See More Case Studies

The Works Detailed Site Plan For A Parking Lot in Texas

The Works Site Plan – TX Parking Lot Event Permit Case Study

Do You Need Engineered Building Plans For Your Project?

Our Friends at Engineering Express specializes in ready-to-use engineered plans for common residential and commercial projects — a great resource when your building department requires more detail.

CERTIFIED REVIEWS

Loved by thousands of homeowners, contractors, and property managers.

We’ll just let our customers do the talking for us.

Residential Site Plans

Basic Plot Plan

This plan includes:

Property Lines
Primary Structure Roofline
Lot Dimensions
North Arrow
Scale

$99

Select Plan

Medium Site Plan | Home Site Plans

This plan includes ALL Basic Site Plan features PLUS:

Measurements Between Features
Trees
Driveway
Accessory Structures Roofline
Swimming Pool

$119

Select Plan

Detailed Site Plan | Residential Properties

This plan includes ALL Medium Site Plan features PLUS:

Paths
Shrubs
Lawn
Landscaping
Septic / Utilities (provided by customer)

$159

Select Plan

Commercial Site Plans

Detailed Site Plans for Commercial Properties

This plan includes:

Property Lines
Primary Structure Roofline
Lot Dimensions
North Arrow
Scale
Measurements Between Features
Trees
Driveway
Accessory Structures Roofline
Paths
Shrubs
Visible Parking Lights
Ingress / Egress
Dumpster Area
Parking Spaces

$179

Select Plan

Sale

The Works Commercial Site Plan

This plan includes ALL Commercial: Detailed Site Plan package PLUS:

Additional Structure (Non-existing)
Legal Setbacks
Custom Size
DWG File
Topography
Impervious Surface Calculation
Vicinity Map

$279 $329

Select Plan

FAQs

What does a parking lot site plan need to include?

A parking lot site plan must show lot dimensions, the number and layout of parking spaces, ADA-compliant stall locations and access aisles, ingress and egress points, landscaping or buffer areas, lighting placement, and setbacks from property lines. Drainage and impervious surface calculations may also be required.

How much does a parking lot site plan cost?

Costs vary based on property size and scope, but most parking lot site plans range from $179–$500, making them a cost-effective step toward permit approval.

Do parking lot site plans include ADA compliance details?

Yes. MySitePlan’s commercial plans include ADA-compliant stall placement, access aisle widths, and ramp locations as required for parking lot permit submissions.

How long does a parking lot site plan take?

Most parking lot site plans are delivered within 24 hours. For larger or more complex commercial sites, turnaround may be up to 48 hours. A rush option is available if you need it faster.
